STANDOFFS CONSEALED HEAD HCCS M3x6-2.4
Product number
On request
Name
HCCS M3x6-2.4
Product
Product group
Type
Material
A2
A max.
6.35
B
4.2
C max.
5.39
D
5.0
D upper tol.
5.4
D lower tol.
4.6
E
1.83
Hole lower tol.
5.41
Hole upper tol.
5.49
Hole depth
1.91
Hole diameter
5.41
L
6.0
L upper tol.
6.4
L lower tol.
5.6
Min. sheet thickness
2.4
Product Code
HCCS
Thread
M3
