M-POWER DOMEHEAD 4.8×14 KMA2/A2 D
Product number
1452600171
Name
4.8x14 KMA2/A2 D
Product
Product group
Type
Material
A2/A2
D
4.8
D upper tol.
n/a
D lower tol.
n/a
dk
10.1
dk upper tol.
10.1
dk lower tol.
n/a
dm
3
Hole lower tol.
4.9
Hole upper tol.
5.1
Hole diameter
4.9 - 5.1
L
14.0
L upper tol.
14.99
L lower tol.
13.01
Max. grip
11.1
Min. grip
1.6
Shear force (N)
5000
k
2.1
p
27
Tensile force (N)
6300
